MAX9526EVKIT+
EVALUATION KIT FOR MAX9526
Maxim Integrated Products
1.MAX9526EVKIT.pdf (18 pages)
Video, Video Processing
No
MAX9526
NTSC/PAL Digital Video Decoder
ITU-Compliant Output
Lead free / RoHS Compliant
Maxim integrated products input devices driver download for windows 8.1
  • Current page: 1 of 18
The MAX9526 evaluation kit (EV kit) is a fully assembled
MAX9526 IC. The MAX9526 is a low-power, high-
performance multistandard video decoder. The EV kit
Vista
graphical user interface (GUI) for exercising the fea-
19-4549; Rev 0; 4/09
Windows, Windows XP, and Windows Vista are registered trademarks of Microsoft Corp.
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
MAX9526EVKIT+
C18, C24–C29,
C19, C20, C30,
C22, C23, C38,
C49, C50, C51
C1, C2, C3,
C15, C16
C40, C47
C31
-compatible software that provides a simple
QTY
________________________________________________________________ Maxim Integrated Products
1
4
5
Ordering Information
capacitors (0603)
0.033µF ±10%, 16V X5R ceramic
Taiyo Yuden EMK107BJ333KA
capacitors (0603)
22pF ±5%, 50V C0G ceramic
Murata GCM1885C1H220J
capacitors (0603)
Devices
10µF ±20%, 16V X5R ceramic
Murata GCM31CR71C106KA64
capacitors (0402)
General Description
2000/XP
®
TYPE
MAX9526 Evaluation Kit
♦ 3.3V ITU-R BT.656 Bit-Parallel Outputs
Input
♦ Standard 75Ω Input/Output Terminations
♦ USB-PC Connection (Cable Included)
♦ On-Board Regulators
♦ Support Optional D1 Serializer
♦ Surface-Mount Components
JU3, JU4, JU11,
DESIGNATION
JU1, JU8, JU9,
Compatible Software
LED1, LED2
JU12, JU14
L1, L2, L3
V/RED
JU20
H2
J1
Maxim
QTY
1
1
3
0
0
0
3
26-pin (2 x 13) header
5-pin header
Right-angle RCA jacks
Not installed, 10-pin (2 x 5) header
Not installed, 2-pin
6-pin (2 x 3) header
Red LEDs (T1-3/4)
TDK MMZ1608R301A
DESCRIPTION
1

MAX9526EVKIT+ Summary of contents

Page 1
Input

... Vista -compatible software that provides a simple graphical user interface (GUI) for exercising the fea- tures of the MAX9526. Ordering Information PART MAX9526EVKIT+ + Denotes lead(Pb)-free and RoHS compliant. DESIGNATION QTY DESCRIPTION C1, C2, C3, C5–C14, C17, 0.1µF ±10%, 16V X7R ceramic C18, C24– ...

Page 2

... Maxim MAX9526AEI+ Low-voltage TTL buffer (48 TSSOP (Top Mark: AVC16244) 1.8V at 120mA LDO linear regulator (5 SC70 Maxim MAX8511EXK18+ (Top Mark: AEF) µMAX is a registered trademark of Maxim Integrated Products, Inc. 2 _______________________________________________________________________________________ Component List (continued) DESIGNATION QTY DESCRIPTION 3.3V at 350mA LDO linear regulator (8 SO Maxim MAX1658ESA+ Passive video switch (10 µ ...

Page 3

SUPPLIER Hong Kong X’tals Ltd. Murata Electronics North America, Inc. Taiyo Yuden TDK Corp. Note: Indicate that you are using the MAX9526 when contacting these component suppliers. FILE MAX9526.EXE FTD2XX.INF USB_Driver_Help.PDF Recommended Equipment • MAX9526 EV kit (USB cable included) ...

Page 4

MAX9526 Evaluation Kit C:Program FilesMAX9526 (default installation directory) using the Browse button. During device driver installation, Windows may show a warning message indicating that the device driver Maxim uses does not contain a digital signature. This is not an error ...

Page 5

Figure 2. Advanced User Interface Window MAX9526 Video Decoder Tab Registers 0x00 and 0x01 are read-only status displays. All the other registers have Read and Write buttons. The Read All and Write All buttons read or write all the MAX9526 ...

Page 6

MAX9526 Evaluation Kit Table 1. Jumper Selection JUMPER SHUNT POSITION 1-2* JU1 2-3 Not installed* JU3 PCB trace cut open Not installed* JU4 PCB trace cut open 1-2 JU5 Open* 1-2 JU6 Open* 1-2 JU7 Open* 1-2* JU8 2-3 1-2* ...

Page 7

Detailed Description of Hardware The MAX9526 EV kit is a fully assembled and tested surface-mount PCB that contains a MAX9526 IC. The MAX9526 is a low-power, high-performance multistan- dard video decoder. External passive video switch U5 (MAX4586) allows evaluation of ...

Page 8

MAX9526 Evaluation Kit Table 4. Jumper Selection for I JUMPER SHUNT POSITION Not installed* JU3 PCB trace cut open Not installed* JU4 PCB trace cut open 1-2* JU8 2-3 1-2* JU10 2-3 Not installed* JU11 PCB trace cut open Not ...

Page 9

I C Device Address Maps 2 Table 6. U1 MAX9526 I C Device Address 2 JU19 MAX9526 I C DEVADR ADDRESS 1-2* 0100 000 r/w (DVDD) 3-4 0100 001 r/w (DGND) 5-6 0100 010 r/w (SDA) * Default position. ...

Page 10

MAX9526 Evaluation Kit Figure 3a. MAX9526 EV Kit Schematic (Sheet ______________________________________________________________________________________ ...

Page 11

Figure 3b. MAX9526 EV Kit Schematic (Sheet ______________________________________________________________________________________ MAX9526 Evaluation Kit 11 ...

Page 12

MAX9526 Evaluation Kit Figure 3c. MAX9526 EV Kit Schematic (Sheet ______________________________________________________________________________________ ...

Page 13

Figure 3d. MAX9526 EV Kit Schematic (Sheet ______________________________________________________________________________________ MAX9526 Evaluation Kit 13 ...

Page 14

MAX9526 Evaluation Kit Figure 4. MAX9526 EV Kit Component Placement Guide—Component Side 14 ______________________________________________________________________________________ ...

Page 15

Figure 5. MAX9526 EV Kit PCB Layout—Component Side ______________________________________________________________________________________ MAX9526 Evaluation Kit 15 ...

Page 16

MAX9526 Evaluation Kit Figure 6. MAX9526 EV Kit PCB Layout—Layer 2 16 ______________________________________________________________________________________ ...

Page 17

Figure 7. MAX9526 EV Kit PCB Layout—Layer 3 ______________________________________________________________________________________ MAX9526 Evaluation Kit 17 ...

Page 18

Maxim Integrated Products Input Devices Driver Download For Windows 10

... Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are implied. Maxim reserves the right to change the circuitry and specifications without notice at any time. 18 ____________________Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 © 2009 Maxim Integrated Products ...
